Power Wheelchair (Model:BC-EA8000)

Features

• This Power wheelchair is a motor driven, indoor and outdoor transportation vehicle, which a device for assisting action handicapped people and disabled people to move. It is suitable for disabled people with mobility difficulties and elderly people
• The device consists of front wheel, drive wheel, frame, controller, motor, armrest, backrest, seat cushion, pedal, battery box and charger.
• The device is powered by Li-ion Battery pack (24V 6Ah) with 10 Km range, which can be recharged by an off-board battery charger that can be plugged into an AC socket outlet (100-240V, 50/60Hz) when the device is not in use
• The patient can activate the controller handle (joystick) to control the speed and direction of the wheelchair movement.
• In addition, when the patient releases the joystick, the joystick will return back to the central position and the wheelchair will be automatically stopped soon due to automatic electromagnetic brake system. Once the joystick is activated again move to other position, the wheelchair will be re-energized.

Description

Common or Usual name: Power WheelchairModel(s): BC-EA8000Indications for use: It is a motor driven, indoor and outdoor transportation vehicle with the intended use to provide mobility to a disabled or elderly person limited to a seated position.Use condition: indoor and outdoor useNumber of wheels: 4,including two front wheels and two rear WheelsFunction of wheels: Front wheels:driven wheels suitable for rotation, acceleration, retrograde Rear wheels: driving wheels to control the speed and directionMovement control method: By Joystick controlDriving system: Direct drive on the rear wheelsBrake system: Automatic electromagnetic brake systemBraking distance: ≤1.5 mMaximum safe operational incline degree: 6°Armrest: PUBattery charger: Off-board charger Input: 100-240V, 50/60Hz, 1.5A, Output: 24 Vdc, 2A;Main frame material: Aluminum AlloyBack cushion: Polyester fabricSeat cushion: rubber patch cloth and Oxford fabricOverall Dimension(lengthwidthheight): 950625930mmFolded Dimension(lengthwidthheight): 775440410mmFront wheel size/type: 5.9" x1.90" / PU Solid tireRear wheel size/type: 10.6" x1.97" / PU Solid tireMax speed forward: Up to 6 km/hMax Speed backward: Less than 3 km/h (0.5 m/s)Max loading weight: 181 Kg (≈400 lbs)Battery: Lithium 24V6AhMaximum distance of travel on the fully charged battery: 10kmMotor: Brushless DC motor; 24VDC;150W, 2pcsElectronic controller: Brushless dual-drive rocker controllerMaximum obstacle climbing: 40 mm

Brand: Yawhew

Color: Black, Yellow

Item Weight: 63.9 Pounds

Style: Power wheelchair (ModelBC-EA8000)

Material: Main frame material Aluminum Alloy, Seat cushion rubber patch cloth and Oxford fabric, Back cushion Polyester fabric See more

Item Weight ‏ : ‎ 63.93 Pounds

Item model number ‏ : ‎ Power wheelchair (ModelBC-EA8000)

Date First Available ‏ : ‎ June 11, 2024

Manufacturer ‏ : ‎ Ningbo Baichen Medical Devices Co., Ltd.
